UHF wireless video conference system unit

Share to:
  • WCS-206C/WCS-206D
Quantity:

WCS-206C

*Discussion/Video-tracking digital conference system unit;

*Metal base shell of the microphone unit.

*Anti electromagnetic interference, mobile phone;

*LCD monitor indicate the working status;

*Chairman has priority control function.Can shut the speech of delegate unit at any time;

*Gooseneck microphone,there is light ring in the microphone head;

*External antenna, enhanced signal transmission;

*Built-in 3.7V big lithium battery,can supported 10 hours.


Technical Parameters:

Power supply:3.7V 2100MA lithium  battery

Emission power:10mW

Maximum frequency deviation:±45KHz

Pickup head:condenser,single direction

Sensitivity:-45±2dB@1KHz

Frequency response:20Hz-18KHz

Power consumption:100mA

Size: 190*125*31mm

Weight: 1000g

Gooseneck mic lenght:435mm


WCS-206D

*Discussion/Video-tracking digital conference system unit;

*Anti electromagnetic interference, mobile phone;

*LCD monitor indicate the working status;

*Gooseneck microphone,there is light ring in the microphone head;

*External antenna, enhanced signal transmission;

*Built-in 3.7V 2100MA big lithium battery,can supported 10 hours.


Technical Parameters:

Power supply:3.7V 2100MA lithium battery

Emission power:10mW

Maximum frequency deviation:±45KHz

Pickup head:condenser,single direction

Sensitivity:-45±2dB@1KHz

Frequency response:20Hz-18KHz

Power consumption:100mA

Size: 190*125*31mm

Weight: 1000g

Gooseneck mic lenght:435mm
