*2 channels. UHF adjustable frequency.
*IR automatic. totally 400(2*200) frequency.Stepping up/down by 0.25MHz.
*Every microphone can use in every channel.
*5 controllers can used simultaneously.
*LCD screens show working status on the receiver and emitter.
*Microphone have mute key.
*There are 2 balanced output and 1 mixed unbalanced output,2 rubber antennas.
*Consumption is 80mA. AA 1.5V*3 battery power supply,support 8 hours.
*Light ring on the microphone head will display working status.
*Working distance: 50-80 meter
*It's suitable for various kinds of conference and performance occasion.
Technical parameter:
Channel number: 2
Oscillation Mode: PLL synthesized
Modulation Mode: FM
Frequency Range: UHF 600-699.75MHz
Frequency Stability : +0.001%
Max. Deviation Range: +50KHz
S/N Ratio : >105dB
T.H.D: <0.5%@1KHz
Sensitivity: 1.2/UV@S/N=12dB
Power Supply: DC 12~17V
Gooseneck mic length:435mm
Audio Output: Independent: 0-400mV
Mixed: 0-300mV
